Mean Well DDR-240C-24 240W DIN Rail Type DC-DC Converter 24V 10A Power Supply

NEW, MEAN WELL Power Supply.DDR-240 series is a 240W DlN Rail type DC-DC converter with main features including DlN rail-type easy installation, ultra slim width (40mm), 2:1 wide input voltage, fanless design, -40~+70℃ wide operating temperature, 4KVdc l/O isolation, 150% peak load, current sharing,DC OK, adjustable output voltage and full protective functions.This series of models has various input options: 16.8~33.6V / 33.6~67.2V / 67.2~154V and two output options: 24V / 48V and can be used for industrial & railway control, security control, communication system and other fields.Suitable applications include to DC buck/boost regulator, increasing system insulation level and voltage drop compensation along cable...etc.

• Ultra Slim Design: Width only 40mm for space-saving installation in compact DIN rail applications
• Wide Operating Temperature Range: Functions reliably in extreme conditions from -40C to +70C for demanding industrial environments
• Peak Load Capability: Delivers 150% peak load capacity to handle temporary power surges and startup requirements
• Current Sharing Function: Supports parallel operation with current sharing up to 960W in 3+1 configuration for increased power output
• Comprehensive Protection Features: Includes short circuit, overload, over voltage, over temperature, input reverse polarity, and input under voltage protection
• High Isolation Rating: Features 4KVdc input to output isolation for enhanced safety and system reliability
• Flexible Input Voltage: 2:1 wide input voltage range accommodates various DC power sources for versatile applications
• Fanless Design: Silent operation with natural convection cooling eliminates noise and maintenance requirements
