Dovetail Groove Stage Optical Positioning Sliding Table Manual Adjust Trimming Bearing Rotation Platform Motion Sliding Table for Precision Equipment Setup Alignment

High-precision worm gear + dovetail guide rail, ±20° vertical adjustment, 360° coarse adjustment + ±5° fine adjustment, 6kg load capacity with rock-solid stability!R-angle scratch-resistant design + anodized aluminum alloy, suitable for optics, semiconductors and other fields, the professional choice!Description:-- Linear platform supports precise angle adjustment and quantitative movement.-- Dovetail guide rail, high precision, strong load capacity, and stable movement.Specifications:Name: Manual Linear PlatformTraction Direction: Aβ axisMaterial: Aluminum AlloyTreatment: Black AnodizedMinimum Graduation: 1°Table Size: 60×60mmCenter Height: 60mmDrive Method: Worm Gear DriveStroke: (Up) ±20° (Down) ±15°Downward Movement Range: Coarse Adjustment 360°, Fine Adjustment ±5°Load Capacity: 58.8N (6kgf)Weight: 1.16kgGuide Type: Precision-machined Dovetail GuideProduct Includes:1 Manual Linear PlatformAfter-Sales Service:If you have any questions about our products, please contact us promptly. We will reply to you as soon as possible within 24 hours. Happy shopping!

• 【HIGH PRECISION RELIABILITY】 : Turbine Worm Dovetail Fine Tune Platform Utilizing a central worm gear and precision-adjustable dovetail guide rails, the movement range is ±20° (upper) and ±5° (lower). It features a coarse adjustment of 360° and a fine adjustment of ±5°. With a load capacity of 58.8N (6kgf), it achieves smooth movement, minimizing deflection and tilting. The minimum reading scale is 1°
• 【R-ANGLE PROTECTION DESIGN】: Dovetail Platform Goniometer 60 x 60 mm worm gear dovetail groove fine-adjustment platform features an R-angle protection design, eliminating edge burrs and preventing impact damage during use, thus improving safety and accuracy
• 【MULTI-FUNCTIONAL WORKTABLE COMBINATION】: Angle Adjustment Platform Easy to use, with an extended handwheel for convenient adjustment, a multi-hole design with standard hole spacing, it can be combined with other worktables and is compatible with other types of stages to create a multi-functional worktable
• 【RUGGED ALUMINUM ALLOY】: Manual linear stage goniometer Black anodized finish minimizes light reflection, making it an ideal choice for optical applications, ensuring durability and wear resistance
• 【WIDE APPLICATIONS】: Linear positioning stage In fields such as optical instruments, measuring equipment, semiconductor manufacturing, testing machines, microscopes and photographic equipment, providing flexibility and accuracy for professional applications
